Product Description
Comprehensive reinforcement with fiberglass mesh enhances safety and controllability
Tough alumina abrasives are continuous
Expose during use to maintain sharp cutting edges
Ultra thin metal cutting discs, due to their reduced thickness, cut faster than traditional cutting discs.
Reduced amount of metal removed, improved cutting speed and reduced heat generated
Suitable for thin-walled profiles and metal plates in structural and container engineering. Often used in car body manufacturing. Also applicable to stainless steel.
CUTTING DISC WHEEL AND GRINDING WHEEL SPECIFICATION
|
Description |
Size: mm |
Size: inch |
PCS/ CTN |
G.W.:KG |
CTN Size: CM |
|
|
Flat Cut off wheel, used for cutting metal, stainless steel, alloy steel,machine parts, tubes,etc. |
41A 400x3x25.4,1net |
16''x1/8''x1'',black |
25 |
22 |
41x41x10 |
|
|
41A 400x3x25.4,2net |
16''x1/8''x1'',black |
25 |
22 |
41x41x10 |
||
|
41A 400x3x25.4, 1net |
16''x1/8''x1'',green |
25 |
22 |
41x41x10 |
||
|
41A 400x3x25.4,2net |
16''x1/8''x1'',green |
25 |
22 |
41x41x10 |
||
|
41A 355x3x25.4,1net |
14''x1/8''x1'',black |
25 |
16 |
37x37x9 |
||
|
41A 355x3x25.4,2net |
14''x1/8''x1'',black |
25 |
16 |
37x37x9 |
||
|
41A 355x3x25.4,1net |
14''x1/8''x1'',green |
25 |
16 |
37x37x9 |
||
|
41A 355x3x25.4,2net |
14''x1/8''x1'',green |
25 |
16 |
37x37x9 |
||
|
41A 305x3x25.4, 1net |
12''x1/8''x1'', |
25 |
13 |
31x31x9 |
||
|
41A 305x3x25.4, 2net |
12''x1/8''x1'', |
25 |
13 |
31x31x9 |
||
|
41A 255x3x25.4,2net |
10''x1/8''x1'' |
50 |
20 |
26x26x18 |
||
|
41WA 230x2x22, |
9''x1/12''x7/8'' |
100 |
21 |
31x25x25 |
||
|
41A 180x3x22,flat |
7''x1/8''x7/8'' |
100 |
19 |
38x20x20 |
||
|
41A 180x2x22,flat |
7''x1/12''x7/8'' |
200 |
23 |
38x25x20 |
||
|
41WA 180x1.6x22 |
7''x1/16''x7/8'' |
200 |
20 |
38x22x20 |
||
|
41A 125x2x22 |
5''x1/12''x7/8'' |
200 |
13 |
27x27x14 |
||
|
41A 125x1.6x22 |
5''x1/16''x7/8'' |
400 |
19 |
27x27x21 |
||
|
41WA 125x1.2x22 |
5''x1/21''x7/8'' |
600 |
19 |
39x32x14 |
||
|
41A 105x1.6x16 |
4''x1/16''x5/8'' |
400 |
14 |
23x23x20 |
||
|
41WA 105x1.2x16 |
4''x1/21''x5/8'' |
600 |
14 |
35x34x13 |
||
|
41ZA 105x1x16 |
4''x1/25''x5/8'' |
600 |
14 |
35x34x13 |
||
|
41WA 75x1.6x9 |
3''x1/16''x5/14'' |
1000 |
19 |
40x27x16 |
||
|
Tapper Ginding disc wheel, |
Flexible |
27WA100x2.5x16 N-F |
4''x1/10''x5/8'' |
360 |
18 |
38x22x22 |
|
27WA 100x2.5x16,F |
4''x1/10''x5/8'' |
360 |
18 |
38x22x22 |
||
|
27GC 100x2.5x16 N-F |
4''x1/10''x5/8'' |
360 |
18 |
38x22x22 |
||
|
27A 100x2.5x16,F |
4''x1/10''x5/8'' |
280 |
18 |
38x22x22 |
||
|
Grinding disc |
27A 100x4x16 |
4''x1/6''x5/8'' |
280 |
22 |
38x22x22 |
|
|
27A 100x6x16 |
4''x1/4''x5/8'' |
200 |
22 |
38x22x22 |
||
|
27A 125x6x22 |
5''x1/4''x7/8'' |
100 |
18 |
26x21x26 |
||
|
27A 180x6x22 |
7''x1/4''x7/8'' |
60 |
21 |
38x24x20 |
||
|
Tapper Cutting disc wheel |
42A 100x3x16 |
4''x1/8''x5/8'' |
320 |
19 |
38x22x22 |
|
|
42A 180x3x22 |
7''x1/8''x7/8'' |
100 |
21 |
38x24x20 |
||
|
42A 230x3x22 |
9''x1/8''x7/8'' |
50 |
16 |
25x25x25 |
||
Why Choose Us
Due to its innovative and unique production process, it may reduce costs by 50% compared to similar products. Significant clearance
Due to the extremely rough side profile, cutting is easier and can prevent recoil effects and brake disc blockage even in extreme situations
Application. Due to the smallest burrs, almost no rework is required. Vibration and cutting greatly reduce the pressure on users
Noise and sparks. Reduce cutting dust by 30%. The super large security buffer zone exceeds the safety requirements of relevant regulations
Due to its highly tear resistant special fabric and innovative product design.
