Name: Grind Wheel Polish
Brand: GUOMAI
SKU: 243534312

Product Description

product-1000-1333

The uniform pad of 10 Inch Non Woven Polishing Wheels are made of high temperature nylon staples to remove burrs and give a smooth finish. These pads form a grinding wheel by compressing multiple layers of unwoven fiber web materials and bonding them together. In 10 Inch Non Woven Polishing Wheels, the combination range has a layered structure, the center hole size can be selected, and there is no core, so it is durable. The edge of the web becomes a cutting tool, while the grinding wheel is non-directional.

CERAMIC BONDED GRINDING WHEEL SPECIFICATION

Diameter: mm	Thickness: mm	Hole:mm	Abrasives material	Grit:	Hardness:	Type:
100×20×20	13-32	20, 25	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat
125×20×20	13-32	20, 25	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat
150×20×32	13-32	20, 25	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat
150×25×32	13-32	20, 25	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat
175×25×32	13-32	20, 25	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat
200×20×32	20-32	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat, taper,C face, cup type, etc
200×25×32	20-32	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat, taper,C face, cup type,
200×32×32	20-32	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat, taper,C face, cup type,
250×20×32	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
250×25×32	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
250×32×32	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
300×32×32	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
300×40×75	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
300×40×127	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
300×50×75	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
300×50×127	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
350×40×75	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
350×40×127	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
350×50×75	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
350×50×127	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
300×40×40	20-50	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
400×40×75	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
400×40×127	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
400×40×203	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
400×50×75	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
400×50×127	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
400×50×203	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
400150203	20-100	25,31.75	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
450X50X127	20-100	25, 100	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
450X50X203	20-100	25, 100	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
500X50X203	20-200	25, 150	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight flat,
500X50X305	20-200	25, 150	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	taper,C face, cup type,
500X150X305	20-200	25, 150	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight,taper
500X200X305	50-300	25, 150	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight,taper
600X50X305	50-300	25, 180	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight,taper
750X75X305	50-300	25, 200	WA, A, GC, C,PA, ZA, MA,SA	24# - 1000#	L,M,N,O,P,Q,R,S,T	Straight,taper

product-1000-667

product-1000-302

product-1000-462

LINYI GUOMAI ABRASIVES is primarily involved in the production and processing of resin-bonded abrasives and ceramic bonded grinding wheels.It was estabblished and started production in March, 1996. The company has strong technical process , reasonable layout of infrastructure facilities, advanced production equipment and complete supporting facilities. Resin bonded abrasive wheels and Ceramic bonded grinding wheels.
